Specifications
Engines
|
Engine type |
24-Valve, DOHC with VCT, 60 deg. V6 |
|
Displacement |
4169 cm³ |
|
Bore x stroke |
96.0 × 96.0 mm |
|
Compression ratio |
10.3 :1 |
|
Fuel induction system |
Fuel injection |
|
Lubrication system |
Wet sump |
|
Engine oil capacity |
6.3 L/ 6.0 L (with / without oil filter replacement) |
|
Ignition / advance system |
TCI |
|
Alternator |
70 A (charging capacity: 48A) |
Dimensions
|
Overall length |
1026 mm |
|
Overall width |
634 mm |
|
Overall height |
X: 1964 mm, U: 2091 mm, E: 2218 mm |
|
Engine transom height |
X: 640 mm, U: 767 mm, E: 894mm |
|
Steering angle |
32 deg. each direction |
|
Dry weight |
288 – 299 kg |
Performance
|
Maximum propeller shaft output |
220.6 kW |
|
Full throttle operating range |
5000 – 6000 r/min |
|
Idling speed |
650 – 750 r/min |
Bracket/Drive
|
Shallow water drive |
PTT: variable position |
|
Gear shift |
F-N-R |
|
Gear ratio |
1.75 (21/12) |
|
Gear oil capacity |
0.925 L / 0.885 L |
