Specifications
Engine:
|
Engine type |
SOHC L4 8 valves |
|
Displacement |
996 cm³ |
|
Bore x stroke |
65.0 × 75.0 mm |
|
Compression ratio |
9.5 : 1 |
|
Fuel induction system |
Fuel injection |
|
Lubrication system |
Wet sump |
|
Engine oil capacity |
2.1 L / 1.9 L (with / without oil filter replacement) |
|
Ignition / advance system |
TCI |
|
Alternator |
16 A (battery charging: 9 A) |
Dimensions
|
Overall length |
EHT, EHD: 1380 mm, ED, ET: 714 mm |
|
Overall width |
384 mm |
|
Overall height |
L: 1439 mm, X: 1553 mm |
|
Engine transom height |
L: 527 mm, X: 641 mm |
|
Steering angle |
40 degrees each direction |
|
Dry weight |
114 kg – 119 kg |
Performance
|
Maximum propeller shaft output |
44.1 kW |
|
Full throttle operating range |
5000 – 6000 r/min |
|
Idling speed |
700 – 800 r/min |
Bracket/Drive
|
Shallow water drive |
ET, EHT: PTT: variable position, ED, EHD: Hydro: variable position |
|
Gear shift |
F-N-R |
|
Gear ratio |
1.85 (24/13) |
